CONTI-V MULTIBELT Banded V-Belts (ISO 4184 / DIN 7753 Wrapped)
CONTI-V MULTIBELT banded V-belts are created by joining individual V-belts into one wide strip. The belt profile and transmitted power remain the same as the individual belts. They are wrapped according to ISO 4184 (DIN 7753).
The banded V-belts are used to eliminate vibrations in the individual belts, on drives with significant impacts as well as highly irregular loads and on drives with large center distances.
Low electrical conductivity – for compliance with requirements to ISO 1813.
Belts Construction
- Fabric jacket
- Natural rubber bottom section
- Polyester tension member
- Natural rubber backing
Belts Fields of Use
The CONTI-V MULTIBELT banded V-belts are used in heavy-duty machines in all industries, especially in agricultural machinery, machine tools, crushers, fans, in the paper industry, cement plants, power plants, mines and in other cases where large irregular forces must be transmitted over long span lengths.
Belts Characteristics
- Temperature range from −40 °C to +80 °C
- Enhanced running smoothness
- Electrically conductive in accordance with ISO 1813
- Conditionally resistant to oil
- Suitable for tropical climates
- Dust-proof
Belts Code Description
Example:
3-HA 2540 Li (3-HA100) CONTI-V MULTIBELT
| Code Part | Description |
|---|---|
| 3 |
3-Banded |
| HA |
Profile |
| 2540 Li |
Inside lenght in mm |
| 3 |
3-Banded |
| HA |
Profile |
| 100 |
Inside lenght in inch |
| CONTI-V MULTIBELT |
Type of belt |
Notice
For HA, HB, HC and HD multiple belts, special pulleys must be used due to the different groove distance e [mm]!
Belts Certification
- Factory Electrical Conductivity Certificate of Belts According to ISO 1813 and ISO 9563 (pdf, 104.90 kB)
- ContiTech Explanation of ATEX Certification (pdf, 11.96 kB)
Notice
General factory certificates are not sufficient for belts used in potentially explosive atmospheres.
If a test report according to ISO 1813 and ISO 9563 is required for the application, it is necessary to inform us of the request for delivery of belts including the certificate when ordering them (when ordering belts via Eshop, please write this request in the "Note" field before by sending the order). The certificate is issued by ContiTech after the test in the production plant.
Documents for Download
Dimensions and Parameters of CONTI-V MULTIBELT HA, HB, HC a HD V-Belts
TYMA CZ Data Sheets
Czech and English (PDF 604.62 kB)
Rubber Products Optional Services Price List
TYMA CZ Product Overview
Czech and English (PDF 500.38 kB)
